    High Brightness P16 Full Color Outdoor Advertising Led Display 8000 Nits

    Ask Lasest Price
    Brand Name : Meltonled
    Certification : CE, RoHS, ISO,FCC,UL
    Model Number : P16-a-2
    Price : 1-100000usd
    Delivery Time : 8-25 days
    Payment Terms : 35% T/T as prepayment,65% T/T as balance at factory
    Supply Ability : >500sqm/month
    • Product Details
    • Company Profile

    High Brightness P16 Full Color Outdoor Advertising Led Display 8000 Nits


    High Brightness P16 Full Color Outdoor Advertising Led Display 8000 Nits


    Specifications


    1.48bit colors processing
    2.Energy saving,Easy maintenance
    3.Advanced dot adjusting
    4.CE,ROHS


    Super brightness full color LED billboard advertising


    1.Show all kinds of word,text,graph, pictures, flashes, video,2-dimension, 3-dimension cartoon and any other

    formats with your PC does synchronously.


    2. Different signal resources input are acceptable, such as TV, HCTV, S-video, NTSC/PAL,DVI, AVI, VGA,SDI,

    MOV,MPG,HD-SDI, etc.


    3.Self-adjustment function

    automatically adjusts outdoor LED display brightness to suitable level through outdoor environment condition


    4.It can be used in advertisement, stage, stadium, exhibition, TV-Show,mansion video wall, shopping mall,

    banks, schools, bus station, airport, gym, market, factories, monitoring centers,hospitals, bars etc.

    1) System structure

    Super brightness full color led billboard advertising for outdoor advertising


    2)Led Module

    Super brightness full color led billboard advertising for outdoor advertising


    Module Size(W * H)

    256mm*128mm

    Pixel Configeration

    2R,1G,1B

    Pixel Pitch

    16mm

    Resolution(W*H)

    16dots*8dots

    Pixel Density

    3906 dot / m2

    Driving Method

    static Current

    3)Led cabinet

    Cabinet Size(W * H)

    1024mm*768mm

    Module Qty

    20pcs

    Cabinet Resolution(W * H)

    64dots*48dots

    Cabinet Pixel

    4096

    Weight

    56kg/pc

    Area

    1.23(m2)

    Avarage Power Consumption

    200W/m2

    Max Consumption

    600W/m2


    4)Led Video wall technical parameter


    Operating Humility

    10% ~ 90% RH

    Oprating Temprature

    -20°C ~ +60°C

    Optimal Viewing Distance

    10m-60m

    Display Color

    1,070,000,000

    Gray Scale

    65536grade

    Brightness control

    256grade

    Frame Frequency

    60HZ

    Refresh Speed

    >300HZ

    Power Supply

    220V/50HZ

    MTBF

    ≥10,000hours

    Life Span (50% brightness)

    ≥100,000hours

    Control Mode

    synchronization with PC

    Input Signal Format

    VGA,DVI,RGBHV,PbPr(HDTV),Composite,S-Video,TV

    Operating System

    WINDOWS(98,2000,XP,Vista)


    Methods for Quality Assurance

    a. Aging

    1. 100% fully test

    2. Condition: 72 hours with 256 grey level


    b. Vibration Testing

    Condition: 3-5 mins up and down in 5mm range


    Factory Equipment


    Wave Soldering Conveyor, PC Console, Wave Soldering Machine,
    Automatic Glue- pouring Machine, Solder Paste Printing Machine,
    Reflow Soldering Machine, Automatic Solder Paste Printing Machine,
    Withstand Voltage Tester, Ground Resistance Tester,
    Medium-speed Automatic SMT Machine, Super Mute Terminal Machine,
    Automatic Wire Stripping Machine, Automatic Optical Inspection (AOI) Equipement.


    Package

    Flight case and Fumigation-Free wooden case


    Control System Connection


    Competitive Advantage:

    1. 2 years’ warranty with free repair service

    2. 24/7 Hours online Remote Support

    3. Solution and PCB design

    4. Free factory training

    5. Onsite installation instruction and regular inspection

    6, Small order accepted.
