    Perimeter 1r1g1b P10mm Full Color Outdoor Advertising Led Display 960mm * 960mm

    Ask Lasest Price
    Brand Name : Meltonled
    Certification : CE, RoHS, ISO,FCC,UL
    Model Number : MLED-O500-97
    Price : 400-450usd
    Delivery Time : 8-25 days
    Payment Terms : 35% T/T as prepayment,65% T/T as balance at factory
    Supply Ability : >500sqm/month
    • Product Details
    • Company Profile

    Perimeter 1r1g1b P10mm Full Color Outdoor Advertising Led Display 960mm * 960mm


    Perimeter 1r1g1b P10mm Full Color Outdoor Advertising Led Display 960mm * 960mm

    Specifications

    1 Quiet,light, steady efficent bright

    2 Lower power consumption

    3 Low cost and easy operation

    4 Good quality and after-sale-service

    5 timely delivery


    P10 OUTDOOR P10 SMD 3IN1 TECHNICAL PARAMETERS



    Unit Module

    ItemParameter
    Model NumberP10-2S
    Module size320mm*160mm
    Pixel pitch10mm
    Pixels Density10000/m2
    Pixel configuration1R1G1B
    LED Package modeSMD3535
    Pixel resolution32dots(W)*16 dots(H)
    Max Power45W
    Module thickness17.05mm
    Weight0.51kg
    Drive typeConstant drive
    Scan mode1/2 1/2can
    Port typeHUB75
    Brightness of white balance7500cd/sqm

    LED

    Cabinet

    Dimension640mm*640mm
    Monomer Module Number8pcs
    Power supply5V/40A*2 pcs
    Thermal dischargefan 1pcs
    Pixel per cabinet64mm*64mm
    Best viewing distance10M50M
    Best viewing angle160(W) 120(H)
    Temperature

    storage:-35+85

    working:-20+50

    Relative humidity10%-95%
    Thickness85mm


    Power

    Working voltageAC220V10%
    Average Power consumption<350W/
    Max.Power consumption<880W/
    Current<20mA(single LED)

    Control system

    CPUPentium4 or above P4
    Operation systemWIN98/2000/NT/XP/WIN7
    Control methodSynchronization

    Main technical

    parameter

    Driving deviceConstant drive IC
    Refresh frequency>2000HZ
    Grey scale/colors

    16384,16.7M

    16384gray level/16.7M colors

    MTBF>9000hours
    Power switchAutomatic switch
    Display Mode800*600/1024*768

    Packaging & Shipping

    Corrugated carton Package:

    This is also for led module,40pcs/carton,Carton Size:66x36x36cm


    Plywood case package:

    In usually, 4pcs cabinet pack into one case,this is for indoor fixed installation led display

    3pcs cabinet pack into one case,this is for outdoor fixed installation led display

    Both for shopping by air and shipping by sea


    Flight case package:

    9pcs cabinet pack into one case,this is for rental led display use with convenient wheels and can move anytime,for long time use.
