    P10 1R1G1B Outdoor Led display board,Epistar+silan chip,full color

    Ask Lasest Price
    Brand Name : Melton
    Model Number : Mled-P10-1
    Certification : CE,ROHS,CCC
    Price : N/A
    Delivery Time : 7-20 days
    Payment Terms : T/T
    Supply Ability : 1000SQM/MONTH
    • Product Details
    • Company Profile

    P10 1R1G1B Outdoor Led display board,Epistar+silan chip,full color


    Item

    Technical Specification


    Pixel

    Pixel pitch: 10mm

    Pixel configuration: 1R1G1B

    Brightness: Red: 1000mcd Green: 2300mcd Blue: 600mcd

    Wave length: Red: 625±2nm Green: 525±2nm Blue: 470±2nm

    Module resolution: 16×16 pixels


    Module

    Module size: 160mmx160mm

    Cabinet size: 960mm×960mm×150mm


    Cabinet

    Cabinet resolution: 3072 pixels

    Cabinet material: Steel

    Gross weight: 55kg

    Module quantity: 36 pcs= 6(w) x 6(h)

    Power consumption : Max.:750W/m² Everage: 260W/m²


    Screen parameter

    Drive method: 1/4 scanning

    Brightness: 8000cd/m²

    IC driver: MBI 5024

    Density: 10000 pixel/m²

    Whole display flatness: ≤ 1mm juncture

    Best view distance: ≥ 10m

    Viewing angle: Horizontal: 120° Vertical: 60°

    Humidity(RH): ≤ 90~95%

    Working temperature: from -30℃ to +60℃

    Working voltage: AC220V/110V±10%

    Refresh frequency: 2400Hz(Zdec) ≥ 300Hz(Linsn)

    Frame rate: ≥ 60Hz

    Protection grade: IP65

    MTBF: More than 10000hrs

    Life time: 100,000 hrs


    Control system

    Control system: Linsn

    Signal interface: DVI

    Communication distance: Internet cable: ≤120m / Fiber cable: 1000m

    Systems operating platforms : XP,WINDOWS(WIN95、WIN98、WIN2000)
