    1R1G1B SMD Indoor Full Color LED Display Screen 128 * 96dots Resolution

    Ask Lasest Price
    Brand Name : Meltonled
    Certification : CE, RoHS, ISO,FCC,UL
    Model Number : P7.62
    Price : 1-100000usd
    Delivery Time : 8-25 days
    Payment Terms : 35% T/T as prepayment,65% T/T as balance at factory
    Supply Ability : >500sqm/month
    • Product Details
    • Company Profile

    1R1G1B SMD Indoor Full Color LED Display Screen 128 * 96dots Resolution


    1R1G1B SMD Indoor Full Color LED Display Screen 128 * 96dots Resolution


    SMD 3 in 1 Indoor Led Screens advertising P7.62 1R1G1B 1/8 Scan 220V/50Hz


    Description:


    Safety. Using the low voltage DC so that no matter the elderly and children can safely operate without potential safety hazard.
    Softness. Using PCB as the substrate and can apply to various advertising model requirements.
    Long lifespan. The normal operating time is 100000 hours. If worked all the day long, it would work
    for at least 10 years.
    Energy conservation and environmental protection. Using the environmental materials and
    low power (0.04W-0.08W) so that cannot result in waste and pollution.
    Easily installation. Using attaching clamp, wire casing, iron wire, iron net and can install on all kinds
    of undertake surface. It can also be installed by the double-sided adhesive because of the light weight.
    Pure color. Using the high bright SMT and the color is pure, downy and no glare


    Applications:


    advertising media, sports stadiums, airport station integrated information dissemination, business
    establishments, public area.




    Function:


    video broadcasting,
    information publishing,
    network remote centralized controlling.
    PH6 super brightness high clear Rental SMD indoor led screen
    Specification:

    Item

    PH7.62

    Cabinet

    Technology

    SMD 3 in 1

    Package Mode

    3528

    Pixel Pitch

    7.62mm

    Usage

    indoor

    Module Size

    244×122mm

    Cabinet Size

    976×732mm

    Pixel Density

    17222dots/m2

    Color Configuration

    1R1G1B

    Cabinet Resolution

    128×96dots

    Main Specification

    Best Viewing Distance

    6~60m

    Viewing Angle

    horizontal ≥120°
    vertical ≥70°

    Temperature

    -20°C~+60°C

    Ave.Consumption

    260 W/m2

    Max.Consumption

    650 W/m2

    Control Mode

    synchronism

    Drive Mode

    1/8 Scan

    White Balance Brightness

    ≥1800cd/m2

    Protection Level

    IP45

    Power Supply

    220V/50Hz

    MTBF

    ≥10000hours

    Life Span

    100, 000hours

    Malfunction Dot Rate



    Competitive Advantage:


    1, Good quality;
    2, Good price;
    3, Good 24hours service;
    4, Promote delivery;
    5, Energy-saving;
    6, Small order accepted.
