Full color smd Waterproof 3G taxi billboard advertising 5mm Pixel

Melton optoelectronics co., LTD
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap Full color smd Waterproof 3G taxi billboard advertising 5mm Pixel from wholesalers

    Buy cheap Full color smd Waterproof 3G taxi billboard advertising 5mm Pixel from wholesalers
    • Buy cheap Full color smd Waterproof 3G taxi billboard advertising 5mm Pixel from wholesalers
    • Buy cheap Full color smd Waterproof 3G taxi billboard advertising 5mm Pixel from wholesalers
    • Buy cheap Full color smd Waterproof 3G taxi billboard advertising 5mm Pixel from wholesalers
    • Buy cheap Full color smd Waterproof 3G taxi billboard advertising 5mm Pixel from wholesalers
    • Buy cheap Full color smd Waterproof 3G taxi billboard advertising 5mm Pixel from wholesalers

    Full color smd Waterproof 3G taxi billboard advertising 5mm Pixel

    Ask Lasest Price
    Brand Name : Meltonled
    Model Number : P5
    Certification : CE, RoHS, ISO,FCC,UL
    Price : 1-100000usd
    Payment Terms : 35% T/T as prepayment,65% T/T as balance at factory, Western Union, MoneyGram
    Supply Ability : >500sqm/month
    Delivery Time : 8-25 days
    • Product Details
    • Company Profile

    Full color smd Waterproof 3G taxi billboard advertising 5mm Pixel

    Full color smd Waterproof 3G taxi billboard advertising 5mm Pixel


    Specifications


    1Pixel Pitch5mm
    2Pixel Configuration3-in-1 1R1G1B
    3Pixel Density40000 dot/ m2
    4Module Size160*160mm
    5Module Resolution32 *32dot
    6Module input Voltage4.2V
    7Max Consumption500W
    8Average Consumption250W
    9White Balance Color6000-15000K
    10Frame SizeL:1100mm H:410mm,W:157mm(bottom),75mm(top)
    11Net Screen Size960mm*320mm
    12Screen Resolution192*64 dot
    13Brightness>3300cd/ m2
    14Contrast Contrast>8000:1
    15Horizontal View Angle120°
    16Vertical View Angle120°
    17Optimal Viewing Distance5m
    18Defects Rate≤1/10000
    19Color16777216
    20Brightness ControlRed,Green and Blue 256 Grade/Each
    21Brightness Control100 continuously adjustable, automatic / manua
    22Repetition Frequency>60-85Hz
    23Scan Frequency>1920Hz
    24Scan Mode1/8 scan
    25Driving MethodConstant current
    26Power supplyDC12V
    27Life Span100,000 hours
    28Brightness Change Rate<5%
    29Color Temperature3500~12000 (White Field:6500-12000)
    30White Balance CoordinateAround X:Y=0.27:0.29
    31Control Mode3G/4G/Earthen net
    32GPSYes
    33Screen Surface Flatness<1mm
    34Temperature Operating-30°~+60°
    35Working Humidity10%–95%RH
    36Screen ProtectionWaterproof, rust-proof, dust-proof, anti-static, anti-mildew
    37Power ProtectionWith over-temperature, over-current, over-voltage protection
    38UniformityBetween adjoin pixels: ≤5%; Between adjoin modules:≤3%
    39Mechanical PrecisionModule flatness <1.5mm patchwork accuracy <1mm
    40Screen Weight23 kg


    Applications:


    Competitive Advantage:

    1. Automatic production. More than 90% production process is automatic.


    2. Quality control. We can control the quality of the original materials by ourselves, such as we can do the encapsulation for LEDs by ourselves.


    3. The most competitive price. Because most of the original material we can produce by ourselves. So the cost for us is lower too.


    4. The most professional technical support. We have been in this industry almost 10 years, we have a lot of experience to resolve all kinds of problems.


    5. The best customer service. We can offer you the best customer service both before and after sales. You can reach us 24 hours every day and 7 days a week.


    6. Two years warranty. We are confident about our products quality, so we have no problem at all to offer customers two years warranty.
