Professional commercial Taxi LED Display SMD fixed installation
HD Full color LED Taxi Roof Sign with logo advertising:
1)High cost performance.
2) Good Consistency and High resolution.
3)High brightness and refresh rate .
4)Good after-sale services.
5)In the premise of guaranteeing quality,our company sales at low
profit and warranty for 3 years.
Product Description
| Display Specification |
| 1 | Pixel pitch | 5 mm |
| 2 | Resolution | 40,000 dots/sq.m |
| 3 | Display size (each side) | W 0.96 × H 0.32 = 0.3072 sq.m |
| 4 | Screen resolution (each side) | W 192 × H 64 = 12,288 |
| 5 | Total module quantity (each side) | W 6 × H 2 = 12 pcs |
| 6 | Total cabinet quantity | 1 pc |
| 7 | Cabinet size (including frame) | W 1060× H 400 × D 135mm |
| 8 | Power consumption (Max.) | 650 W |
| 9 | Power consumption (Ave.) | 435 W |
| 10 | Maximum Current | 54.5 Amp |
| LED Module Specification |
| 11 | LED composition | 1R 1G 1B |
| 12 | LED type | SMD3528 |
| 13 | Module resolution | W 32 × H 32 |
| 14 | Module size | W 160 × H 160 mm |
| 15 | Driving method | 1/8 scan constant current |
| Cabinet Specification |
| 16 | Cabinet material | Aluminum cabinet with frame |
| 17 | Cabinet color | Silver |
| 18 | Cabinet weight | about 23 kg |
| 19 | Flatness | Less than 1mm juncture |
| Optical Parameters |
| 20 | Brightness | 3,000 nits/sqm |
| 21 | Viewing angle | Horizontal 140°, vertical 140° |
| 22 | Minimum viewing distance | 5 m |
| Power Supply |
| 23 | Power supply | DC 9 ~ 36V |
| 24 | Output voltage | DC 5V |
| Control System |
| 25 | Control card | Sheenled/xixun |
| 26 | Memory | 4G |
| 27 | Control method | 3G |
| 28 | Refresh rate | 480 HZ |
| 29 | Refresh frame frequency | 60~85 HZ |
| Formats Supported |
| 30 | Video | AVI, WMV, MPG, MOV, DAT, VOB, MP4, FLV |
| 31 | Animation | GIF, SWF |
| 32 | Picture | JPG, BMP, WMF |
| Reliablity |
| 33 | Protection grades | IP65 |
| 34 | Work temperature | -20~+60ºC |
| 35 | Humidity(RH) | 10~90% |
| 36 | LED Life span | More than 100,000 hours |
| 37 | MTBF | 10000 hours |
| 38 | Out of controll dot rate | Less than 1/10,000 |
Specifications
1)High definition and high brightness led screen outdoor;
2)Long durability and high reliability led screen outdoor;
3)Advance video control system and Super input system;
4)Low maintenance cost led screen outdoor;
5)Vividly display led screen outdoor ;
6)Wide viewing angle led screen outdoor;
7)Easy installation and maintenance;
Description:
3G and GPS LED Taxi Top Display
Outdoor LED Taxi Top Display is a new type of electronic media
advertising with elegant and attractive appearance, mainly
installed on taxis, buses and other vehicles as a terminal carrier,
the purpose is to form a new generation of networked, intelligent,
digital outdoor media. This media is an integration of outdoor,
electronics, mobile and Wi-Fi etc.
Applications:
pulic car ,taxi, truck
Competitive Advantage:
1)Training after order
After the order is placed, a processional training will be offered,
including software use, operate safety, maintain equipment
2) Installation and debugging
Wecould send professionals to conduct on site installation and
debugging in strict accordance with the requirements of the schemes
and original manual.
3) Warranty
Warranty: 3 years warranty, lifetime maintenance
Equip with free spare parts. The first 2 years after shipment, we
will be responsible for free maintenance if any problem caused by
quality itself. While you should take the cost of the freight to
us. After 2 years, service is still available, but would charge for
labor, material and freight cost that generates.
4) Maintenance
Maintenance principles: response in time, solve problems asap and
ensure the use.
Maintenance period: In the maintenance period of the led display
body, free of all maintenance charges
After maintenance period, only charge the material cost and labor
cost.
