P6mm P5mm Outdoor Full Color SMD LED Display Taxi Roof Top Signs Programmable

Melton optoelectronics co., LTD
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap P6mm P5mm Outdoor Full Color SMD LED Display Taxi Roof Top Signs Programmable from wholesalers

    Buy cheap P6mm P5mm Outdoor Full Color SMD LED Display Taxi Roof Top Signs Programmable from wholesalers
    • Buy cheap P6mm P5mm Outdoor Full Color SMD LED Display Taxi Roof Top Signs Programmable from wholesalers
    • Buy cheap P6mm P5mm Outdoor Full Color SMD LED Display Taxi Roof Top Signs Programmable from wholesalers
    • Buy cheap P6mm P5mm Outdoor Full Color SMD LED Display Taxi Roof Top Signs Programmable from wholesalers
    • Buy cheap P6mm P5mm Outdoor Full Color SMD LED Display Taxi Roof Top Signs Programmable from wholesalers
    • Buy cheap P6mm P5mm Outdoor Full Color SMD LED Display Taxi Roof Top Signs Programmable from wholesalers
    • Buy cheap P6mm P5mm Outdoor Full Color SMD LED Display Taxi Roof Top Signs Programmable from wholesalers
    • Buy cheap P6mm P5mm Outdoor Full Color SMD LED Display Taxi Roof Top Signs Programmable from wholesalers

    P6mm P5mm Outdoor Full Color SMD LED Display Taxi Roof Top Signs Programmable

    Ask Lasest Price
    Brand Name : Mled
    Model Number : T-P5-1
    Certification : CE RoHS
    Price : 1USD-100000USD
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 50000PS
    Delivery Time : 5-10 days
    • Product Details
    • Company Profile

    P6mm P5mm Outdoor Full Color SMD LED Display Taxi Roof Top Signs Programmable

    P6mm P5mm Outdoor Full Color SMD LED Display Taxi Roof Top Signs Programmable

    Specifications

    Product Description

    Display Specification
    1Pixel pitch5 mm
    2Resolution40,000 dots/sq.m
    3Display size (each side)W 0.96 × H 0.32 = 0.3072 sq.m
    4Screen resolution (each side)W 192 × H 64 = 12,288
    5Total module quantity (each side)W 6 × H 2 = 12 pcs
    6Total cabinet quantity1 pc
    7Cabinet size (including frame)W 1060× H 400 × D 135 mm
    8Power consumption (Max.)650 W
    9Power consumption (Ave.)435 W
    10Maximum Current54.5 Amp
    LED Module Specification
    11LED composition1R 1G 1B
    12LED typeSMD3528
    13Module resolutionW 32 × H 32
    14Module sizeW 160 × H 160 mm
    15Driving method1/8 scan constant current
    Cabinet Specification
    16Cabinet materialAluminum cabinet with frame
    17Cabinet colorSilver
    18Cabinet weightabout 23 kg
    19FlatnessLess than 1mm juncture
    Optical Parameters
    20Brightness3,000 nits/sqm
    21Viewing angleHorizontal 140°, vertical 70°
    22Minimum viewing distance5 m
    Power Supply
    23Power supplyDC 9 ~ 36V
    24Output voltageDC 5V
    Control System
    25Control cardSheenled
    26Memory4G
    27Control method3G
    28Refresh rate480 HZ
    29Refresh frame frequency60~85 HZ
    Formats Supported
    30VideoAVI, WMV, MPG, MOV, DAT, VOB, MP4, FLV
    31AnimationGIF, SWF
    32PictureJPG, BMP, WMF
    Reliablity
    33Protection gradesIP65
    34Work temperature-20~+60ºC
    35Humidity(RH)10~90%
    36LED Life spanMore than 100,000 hours
    37MTBF5000 hours
    38Out of controll dot rateLess than 1/10,000

    Products Advantages:

    1) Price Advantage: we have the best competitive price at the market; also have the same even better quality;
    2) Performance Advantage: Best Equality, high consistency, Big viewing angle, can repair each led lamps;
    3) Quality advantage: From material to finished product, from design to produce, we control all steps that are the guarantee of the quality and reliability;
    4) Service advantage: Better service at same situation, better cooperation at same service.



    Packaging & Shipping

    wooden case or flight case



    Our Services

    1) Your inquiry related to our products or price will be replied in 24hrs


    2) OEM&ODM,any your customized lightings we can help you to design and put into product

    3) Distributoership are offered for your unique design and some our current models

    4) Protection of your sales area,ideas of design and all your private information

    5) Top Quality+Reasonable Price+Responsible After Service=Successful & Win

    Product Tags:

    led taxi display



    taxi top led display


    Quality P6mm P5mm Outdoor Full Color SMD LED Display Taxi Roof Top Signs Programmable for sale
