    IP67 1R1G1B Led Billboard Display 16384 grade 2 Years’ Warrantee

    Ask Lasest Price
    Brand Name : Meltonled
    Model Number : P10-O10
    Certification : CE, RoHS, ISO,FCC,UL
    Price : 450-480usd/sqm
    Payment Terms : 35% T/T as prepayment,65% T/T as balance at factory, L/C, Western Union, MoneyGram
    Supply Ability : >50000sqm/month
    Delivery Time : 15-20 working days
    • Product Details
    • Company Profile

    IP67 1R1G1B Led Billboard Display 16384 grade 2 Years’ Warrantee

    IP67 1R1G1B Led Billboard Display 16384 grade 2 Years’ Warrantee


    Competitive Advantage:

    1. 2 years’ warrantee with free repair service

    2. 24/7 Hours online Remote Support

    3. Solution and PCB design

    4. Free factory training

    5. Onsite installation instruction and regular inspection

    6, Small order accepted.


    Parameter

    LED

    Color

    Model

    Wavelength

    Brightness

    Red

    Oval346

    625-630nm

    ≥1800mcd

    IP67 1R1G1B Led Billboard Display 16384 grade 2 Years’ Warrantee

    Green

    Oval346

    515-520nm

    ≥3800mcd

    Blue

    Oval346

    465-470nm

    ≥800mcd

    UNIT

    Tbar-20

    Leds Configuration

    1R1G1B

    Unit Size

    1600×320mm; 1280×320mm;

    Pixel Pitch

    20mm

    Resolution

    2500dot/m²

    Resolution/unit

    80dot×16dot; 64dot×16dot

    Transparency

    35%

    Brightness

    ≥7000 nit

    Weight


    17kg/ m²

    Max.Power Consumption

    400w/ m²

    Stick Permutation

    Horizontal/Vertical

    Viewing Angle

    H120°/V60°

    Ingress Protection

    IP67

    SYSTEM PARAMETERS

    Color Temperature

    3200K—9300K

    Voltage

    AC220V/50HZ; or AC110V/60HZ

    continuous operating hours

    ≥72 h

    MTBF

    ≥100,000 h

    Out-of-Control Rate

    <1/10000

    Operating environment

    Temperature: -20℃ to +60℃; Humidity: 10%-90%

    Colors

    14 Bit Full Color

    Gray Scale

    16384 grade

    Frame Rate

    ≥60 Hz

    Refresh Rate

    ≥1000 Hz

    LED to LED Calibration

    Yes


    IP67 1R1G1B Led Billboard Display 16384 grade 2 Years’ Warrantee

    Packing&shipping


    Payment terms:T/T in advance, 30% deposit and the balance 70% will be paid before shipment.

    Delivery time:10-12 days

    Warranty time:2years,offer the free spare parts(module & power supply) in advance.After guarantee term,still supply spare parts with charging only materials cost.

    Packing:Standard wooden case packing free,flight case packing.
