    P5 Full Color Video Taxi LED Display , 1/8 Scan Truck Mobile LED Display Board

    Ask Lasest Price
    Brand Name : Mled
    Model Number : T-P5-0s
    Certification : CE ROHS
    Price : 690USD-1000USD/PC
    Payment Terms : T/T, Western Union, MoneyGram, L/C
    Supply Ability : 100000PCS/MONTH
    Delivery Time : 5-10 days
    • Product Details
    • Company Profile

    P5 Full Color Video Taxi LED Display , 1/8 Scan Truck Mobile LED Display Board

    P5 Full Color Video Taxi LED Display , 1/8 Scan Truck Mobile LED Display Board


    Product Description

    Product Features:


    1.Well Designed Cooling Syetem


    2.Aliminum Casting with ultra thin,light weight design


    3.Easy maintenance& IP65 design&long Lasting Display


    4.Organized internal wire harnessing


    5.Powerful control software


    6.Supports flash,picture,video and text


    7.3G High Speed data Transfering


    8.A variety of connection mode, real-time information publish.


    Display Specification
    1Pixel pitch5 mm
    2Resolution40,000 dots/sq.m
    3Display size (each side)W 0.96 × H 0.32 = 0.3072 sq.m
    4Screen resolution (each side)W 192 × H 64 = 12,288
    5Total module quantity (each side)W 6 × H 2 = 12 pcs
    6Total cabinet quantity1 pc
    7Cabinet size (including frame)W 1012 × H 408 × D 160 mm
    8Power consumption (Max.)650 W
    9Power consumption (Ave.)435 W
    10Maximum Current54.5 Amp
    LED Module Specification
    11LED composition1R 1G 1B
    12LED typeSMD3528
    13Module resolutionW 32 × H 32
    14Module sizeW 160 × H 160 mm
    15Driving method1/8 scan constant current
    Cabinet Specification
    16Cabinet materialAluminum cabinet with frame
    17Cabinet colorSilver
    18Cabinet weightabout 23 kg
    19FlatnessLess than 1mm juncture
    Optical Parameters
    20Brightness3,000 nits/sqm
    21Viewing angleHorizontal 140°, vertical 70°
    22Minimum viewing distance5 m
    Power Supply
    23Power supplyDC 9 ~ 36V
    24Output voltageDC 5V
    Control System
    25Control cardSheenled
    26Memory4G
    27Control method3G
    28Refresh rate480 HZ
    29Refresh frame frequency60~85 HZ
    Formats Supported
    30VideoAVI, WMV, MPG, MOV, DAT, VOB, MP4, FLV
    31AnimationGIF, SWF
    32PictureJPG, BMP, WMF
    Reliablity
    33Protection gradesIP65
    34Work temperature-20~+60ºC
    35Humidity(RH)10~90%
    36LED Life spanMore than 100,000 hours
    37MTBF5000 hours
    38Out of controll dot rateLess than 1/10,000

    The functions of control system:


    1. Off-computer after typed in the contents, one main board and several receiving boards.


    2. The effect is as good as the main stream synchronous card, own the perfect playing effect


    3. It has complete display function dominated by videos , and supports images and words.


    4. It’s especially suitable for bar display, and the ultra-long or high length-width ratio is different from that of computer and TV display.


    5. It’s designed based on products. We don’t undertake the project and add special functions without permission, and give priority to the stability.


    6. We don’t’ work on the control of large LED, but focus on the low-cost and easily maintainable LED display.


    7. It isn’t the video-type asynchronization and has long memory of programs. It can collect the temperature and automatically adjust the brightness.
