    Factory Low Price Customized size P8 Full Color Outdoor LED Display

    Ask Lasest Price
    Brand Name : MLED
    Model Number : P8
    Certification : CE, RoHS, FCC, ISO9001, TUV
    Price : USD520/sqm
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : <3500SQM per month
    Delivery Time : 5-25 days
    • Product Details
    • Company Profile

    Factory Low Price Customized size P8 Full Color Outdoor LED Display


    Customized size P8 Full Color Outdoor Front Service LED Display


    P8 Full Color Indoor Outdoor Front Service LED Display Screen for advertising is very hot sale for outdoor mediasolution series, it is very cost effective, and high refresh rate , also light weight design cabinet for options,
    image quality is top, running stable, resolution is high density, plus simple installation to make this series more and more popular in indoor outdoor media screens.


    TECHNICAL PARAMETER


    Unit ModuleItemParameter
    Model NumberP8-4S
    Module size256mm*128mm
    Pixel pitch8mm
    Pixels Density15625dots/m2
    Pixel configuration1R1G1B
    Package modeSMD3535
    Pixel resolution32dots(W)*16 dots(H)
    Max Power35W
    Module thickness17.05mm
    Weight0.343kg
    Drive typeConstant drive
    Scan mode1/4scan
    Port typeHUB75-A
    Brightness of white balance≥6500cd/m2

    LED

    Cabinet

    Dimension768X768mm
    Monomer Module Number18piece
    Power supply5V/60A*3 pcs or 5V40A 4pcs
    Thermal discharge
    Pixel per cabinet128X128dots
    Best viewing distance8M~40M
    Best viewing angle160°(W) 120°(H)
    Temperature

    storage:-35℃~+85℃

    working:-20℃~+50℃

    Relative humidity10%-95%
    Thickness135mm

    PowerWorking voltageAC220V±10%
    Average Power consumption280W/㎡
    Max.Power consumption

    ≤700W/㎡


    Current≤20mA(single LED)
    Control systemCPUPentium4 or above P4
    Operation systemWIN98/2000/NT/XP/WIN7
    Control methodSynchronization

    Main technical

    parameter

    Driving deviceConstant drive IC
    Refresh frequency≥1200HZ
    Grey scale/colors

    4096 16.7M

    4096gray level/16.7M colors

    MTBF≥9000hours
    Power switchAutomatic switch
    Display Mode≥800*600/1024*768


    Factory Low Price Customized size P8 Full Color Outdoor LED DisplayFactory Low Price Customized size P8 Full Color Outdoor LED Display
