    Waterproof 8000cd Led Advertising Billboard P10 High Brightness 3 Years Warranty

    Ask Lasest Price
    Brand Name : MLED
    Model Number : p10
    Certification : CE, RoHS, UL, CCC, FCC
    Price : 7-10usd /pc
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 100000PC/month
    Delivery Time : 10-15days
    • Product Details
    • Company Profile

    Waterproof 8000cd Led Advertising Billboard P10 High Brightness 3 Years Warranty

    Outdoor Full Waterproof 8000 CD LED DisplayP10 Visual Advertising LED Billboard Screen


    TECHNICAL PARAMETERS

    Unit ModuleItemParameter
    Model NumberP10-4S
    Module size320mm*160mm
    Pixel pitch10mm
    Pixels Density10000dots/m2
    Pixel configuration1R1G1B
    Package modeDIP346
    Pixel resolution32dots(W)*16dots(H)
    Max Power35W
    Module thickness16-18mm
    Weight0.88kg
    Drive typeConstant drive
    Scan mode1/4scan
    Port typehub75
    Brightness of white balance≥7500cd/m2

    LED

    Cabinet

    Dimension640mm*640mm
    Monomer Module Number8
    Power supply5V/60A*1 pcs
    Thermal dischargeanto
    Pixel per cabinet64*64dots
    Best viewing distance6M~40M
    Best viewing angle160°(W) 120°(H)
    Temperature

    storage:-35℃~+85℃

    working:-20℃~+50℃

    Relative humidity10%-95%
    Thickness80mm

    PowerWorking voltageAC220V±10%
    Average Power consumption270W/㎡
    Max.Power consumption

    ≤680W/m2


    Current≤20mA(single LED)
    Control systemCPUPentium4 or above P4
    Operation systemWIN98/2000/NT/XP/WIN7
    Control methodSynchronization

    Main technical

    parameter

    Driving deviceConstant drive IC
    Refresh frequency≥1200HZ
    Grey scale/colors4096gray level/16.7M colors
    MTBF≥9000hours
    Fire rateGrade one
    Display Mode≥800*600/1024*768

    HERE ARE SOME PICTURES FOR REFERENCE
    OUR ADVANTAGES
    Melton is a professional manufacturer of Led Module/ Indoor Outdoor LED Display//Rental Stage Led Display/Led Strip Display/Taxi
    Top Led Display/Lamp Pole Led Display/ Led Billboard in Shenzhen.
    Our Company: Melton covers 2000square meters with super clean, antistatic workshop, the most advanced equipment, patching,
    soldering tin, gluing, aging and testing, have own patented technology.

    Our products: are CE approved, RoHS compliant, C-TICK and FCC certificated

    MELTON is always focus on the competitive price, High quality and Best services to each customer, our core value is "Quality
    Assurance, Lifetime Service" and guarantee to the customers: No Complaint
    At the same time MELTON strives to benefit employee shareholders and business partners.
    We balance the short-term and long-term benefits to realize sustained development.

    For our Customer: Good price high quality products and 24hours services
    For our Staff: Providing good sale environment and good welfare
    For our Shareholder: Honest cooperation and double win.
    For Society: Make the world bright make the earth gree.

    FAQ


    1. How long could i receive the inquiry reply ?
    A: You will get a reply within 12 hours.

    2.How to proceed an order for led display?
    A:Firstly let us know your requirements or application
    Secondly we quote according to your requirements or our suggestions.


    Thurdly customer confirms the design document and places deposit for formal order.
    Fourthly we arrange the production

    3.What kind of led display do you offer ?
    A: Different product offer different time frame warranty, but all product here we offer 2 year at least warranty

    4.How long will it take to deliver goods ?
    A: We will start preparing goods when we get your bank receipt. The package will be shipped out in 1-2 working days after we get
    your payment.

    5.How is the after sales service ?
    A: We have a professional team which is in all around the world , also a service hot-line dealing with your complains and
    feedback.We also offer 24-hour online service to help you solving problems1. How long could i receive the inquiry reply ?
    A: You will get a reply within 12 hours.
