    Waterproof Full Color LED Display Board High Brightness Pixel Pitch 6mm IP43

    Ask Lasest Price
    Brand Name : mled
    Model Number : p6
    Certification : CE, RoHS,FCC
    Price : 11-15usd/pc
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 10000pc per month
    Delivery Time : 11-15days
    • Product Details
    • Company Profile

    Waterproof Full Color LED Display Board High Brightness Pixel Pitch 6mm IP43

    Waterproof Full Color LED Display Board


    Parameter


    Unit ModuleItemParameter
    Model NumberP6-8S
    Module size192mm*192mm
    Pixel pitch6mm
    Pixels Density27777点/m2
    Pixel configuration1R1G1B
    Package modeSMD2727
    Pixel resolution32dots(W)*32 dots(H)
    Max Power26W
    Module thickness22mm
    Weight0.56kg
    Drive typeConstant drive
    Scan mode1/8scan
    Port typehub75
    Brightness of white balance≥6000cd/m2

    LED

    Cabinet

    Dimension576mm*576mm
    Monomer Module Number9
    Power supply5V60A 1pcs
    Thermal dischargefan 1pcs
    Pixel per cabinet96mm*96mm
    Best viewing distance6M~40M
    Best viewing angle160°(W) 120°(H)
    Temperaturestorage:-35℃~+85℃working:-20℃~+50℃
    Relative humidity10%-95%
    Thickness125mm

    PowerWorking voltageAC220V±10%
    Average Power consumption280W/㎡
    Max.Power consumption

    ≤680W/㎡


    Current≤20mA(single LED)
    Control systemCPUPentium4 or above P4
    Operation systemWIN98/2000/NT/XP/WIN7
    Control methodSynchronization

    Main technical

    parameter

    Driving deviceConstant drive IC
    Refresh frequency≥1200HZ
    Grey scale/colors4096gray level/16.7M colors
    MTBF≥9000hours
    Fire rateGrade one
    Display Mode≥800*600/1024*768



    About Us

    Melton is a professional manufacturer of Led Module/ Indoor Outdoor LED Display//Rental Stage Led Display/Led Strip Display/Taxi
    Top Led Display/Lamp Pole Led Display/ Led Billboard in Shenzhen.
    Our Company: Melton covers 2000square meters with super clean, antistatic workshop, the most advanced equipment, patching,
    soldering tin, gluing, aging and testing, have own patented technology.

    Our products: are CE approved, RoHS compliant, C-TICK and FCC certificated

    MELTON is always focus on the competitive price, High quality and Best services to each customer, our core value is "Quality
    Assurance, Lifetime Service" and guarantee to the customers: No Complaint
    At the same time MELTON strives to benefit employee shareholders and business partners.
    We balance the short-term and long-term benefits to realize sustained development.

    For our Customer: Good price high quality products and 24hours services
    For our Staff: Providing good sale environment and good welfare
    For our Shareholder: Honest cooperation and double win.
    For Society: Make the world bright make the earth green.
