    Factory price Manufacturer Supplier Indoor P4.81 led stage screen

    Ask Lasest Price
    Brand Name : MLED
    Model Number : P4.81
    Certification : CE-ROHS
    Price : USD 247-300 piece
    Payment Terms : L/C, D/A, T/T, Western Union, MoneyGram
    Supply Ability : 100000 piece per month
    Delivery Time : 8-15work day
    • Product Details
    • Company Profile

    Factory price Manufacturer Supplier Indoor P4.81 led stage screen

    Factory price Manufacturer Supplier Indoor P4.81 led stage screen

    Product description


    1,All die-cast aluminum housing uses 500*500mm,precision seamless,slim and lightweight;

    wrench between the box by latching type connection,easy installation and removal.


    2,SMD-black light,large viewing angle,high contrast,soft image;automatic fanless cooling desgin,

    good heat dissipation,zero noise.


    P4.81 parameter


    Unit ModuleItemParameter
    Model NumberP4.81-13S
    Module size250mm*250mm
    Pixel pitch4.81mm
    Pixels Density43264dots/m2
    Pixel configuration1R1G1B
    LED Package modeSMD2121
    Pixel resolution52dots(W)*52 dots(H)
    Max Power32W
    Module thickness14.66mm(exclude magnet)
    26.55mm(Include magnet)
    Weight0.575kg
    Drive typeConstant drive
    Scan mode1/13scan
    Port typeHUB75-A
    Brightness of white balance≥1200cd/m2

    LED

    Cabinet

    Dimension500mm*500mm
    Monomer Module Number4
    Power supply5V/40A*1pcs
    Thermal dischargefan 1pcs
    Pixel per cabinet104*104
    Best viewing distance5M~20M
    Best viewing angle160°(W) 120°(H)
    Temperature

    storage:-35℃~+85℃

    working:-20℃~+50℃

    Relative humidity10%-95%
    Thickness65mm

    Power

    Working voltageAC110~220V±10%
    Average Power consumption168W/㎡
    Max.Power consumption≤560W/㎡
    Current≤20mA(single LED)

    Control system

    CPUPentium4 or above P4
    Operation systemWIN98/2000/NT/XP/WIN7
    Control methodSynchronization

    Main technical

    parameter

    Driving deviceConstant drive IC
    Refresh frequency≥1200HZ
    Grey scale/colors

    4096 16.7M

    4096gray level/16.7M colors

    MTBF≥9000hours
    Power switchAutomatic switch
    Display Mode≥800*600/1024*768


    Packaging and shipping


    1.Carton box:It is the cheapest packing method for the led display,which is mainly for the small screen

    and short shipping distance.


    2.Wooden case: wooden case packing is the only way and the best way for packing since the low cost

    and same safety level for one timeusing.


    3.Flight case: has wheels and handles which is for the rental use led display, to make the transportation

    be very convenient and protect the led display better



    FAQ


    1,How to be our distributor

    To be our distributor, We can share our profit together with you in every year, Also we can send our

    engineer or sales to your company to support your business, also for led screen after-service,

    We will together with you to the after-service in the whole led screen life time


    2, What is our warranty

    Our warranty from 5 year to 1 years basis on different type led screen, In usually every screen we will

    ready more extra led screen modules as spare modules, if some modules happen fails, you can replace

    the fail modules by our spare modules, When all the spare modules use out, You can send back these

    modules to us for repair, and we will send to you after repair and testing&aging well


    3,How to maintence led screen

    In usually every year to maintence led screen one time, Clear the led mask, checking the cables connection,

    if any led screen modules fail, You can replace it with our spare modules
