    P2.5 indoor high refresh rate LED screens module wholesalers

    Ask Lasest Price
    Brand Name : Meltonled
    Model Number : P2.5
    Certification : CE, RoHS,FCC
    Price : 658-720usd/sqm
    Payment Terms : 35% T/T as prepayment,65% T/T as balance at factory, MoneyGram, Western Union
    Supply Ability : >50000sqm/month
    Delivery Time : 10-12 days
    • Product Details
    • Company Profile

    P2.5 indoor high refresh rate LED screens module wholesalers

    P2.5 indoor high refresh rate LED screen module wholesalers


    Specification:


    INDOOR P2.5 SMD 3IN1 TECHNICAL PARAMETERS


    Unit Module

    ItemParameter
    Model NumberP2.5-32S
    Module size160mm*160mm
    Pixel pitch2.5mm
    Pixels Density160000/m2
    Pixel configuration1R1G1B
    LED Package modeSMD2121
    Pixel resolution64dots(W)*64 dots(H)
    Max Power25W
    Module thickness15mm
    27mm
    Weight0.232kg
    Drive typeConstant drive
    Scan mode1/32scan
    Port typeHUB75E


    LED

    Cabinet

    Dimension640mm*640mm
    Monomer Module Number8pcs
    Power supply5V/60A*1 pcs
    Thermal dischargeFan0pcs
    Pixel per cabinet192*192
    Best viewing distance3M20M
    Best viewing angle160(W) 120(H)
    Temperature

    storage:-35+85

    working:-20+50

    Relative humidity10%-95%
    Thickness85mm


    Power

    Working voltageAC220V10%
    Average Power consumption<320W/
    Max.Power consumption<780W/
    Current<18mA(single LED)

    Control system

    CPUPentium4 or above P4
    Operation systemWIN98/2000/NT/XP/WIN7
    Control methodSynchronization

    Main technical

    parameter

    Driving deviceConstant drive IC
    Refresh frequency>1920HZ
    / Grey scale/colors

    65536,16.7M

    65536gray level/16.7M colors

    MTBF>9000hours
    Power switchAutomatic switch
    Display Mode800*600/1024*768


    P2.5-32S SMD 3IN1 SPECIFICATION.pdf
